주요 특징

• 300/200/100MHz bandwidth selections ;2 channels

• Real time sample rate is 2GSa/s max.

• Per Channel 20M memory depth and VPO waveform display technology

• Waveform update rate up to 120,000 wfms/s

• 8 “ WVGA TFT LCD display

• Maximum 1M FFT provides higher frequency domain resolution measurements

• High ,low and band pass filter functions

• 29,000 segmented memories and waveform search functions

• I2C/UART/CAN/LIN serial bus trigger and decoding function

• Data log function is able to track signal changes up to 1000 hours

• Network storage function

• Mask test function

• MDO-2000AG equips with a dual channel 25MHz AWG
