주요 특징

• Frequency Range: 9kHz ~ 3.25GHz

• 0.025ppm Frequency Stability and 1ppm aging Rate

• RBW: 1Hz ~ 1MHz (3dB), 6dB EMI Filter: 200Hz, 9kHz, 120kHz, 1MHz

• Fastest sweep time: 204us

• Sensitivity: -149 dBm/Hz (@PreAmp on)

• Built-in Preamplifier, 50dB Attenuator, and Sequence Function

• Built-in EMC pretest function, Quasi-Peak/Average EMI detect mode

• Built-in 2FSK Analysis, AM/FM/ASK/FSK Demodulation & Analysis

• Built-in P1dB point, Harmonic, CHPW, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, N-dB bandwidth, Noise Marker, Frequency Counter, TDP, Gated Sweep

• Built-in Spectrogram, Topographic and Split-Window Display Modes

• Remote control EMI measurement software: SpectrumShot

• Remote Control Interface: LAN, USB, RS-232

• Options: Tracking Generator, GPIB Interface, Battery Pack
