주요 특징

• Frequency Range: 9kHz ~ 3 GHz

• 0.025ppm Frequency Stability and 1ppm aging Rate

• Built-in Preamplifier, 50dB Attenuator, and Sequence Function

• RBW: 1Hz ~ 1MHz

• Sensitivity: -149dBm/Hz (@PreAmp on)

• Built-in AM/FM Demodulation & Analysis

• Built-in P1dB point, Harmonic, Channel Power, N-dB bandwidth, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, Noise Marker, Frequency Counter, Time Domain Power, Gated Sweep

• Built-in Spectrogram, Topographic and Dual-View Display Modes

• Remote Control Interface: LAN, USB, RS-232

• Options: Tracking Generator, GPIB Interface
