주요 특징

• Maximum Five Output Channels

• 2 Equivalent Performance Arbitrary Channels Frequency : 1 Hz~10/20/30/60MHz

• RF Channel Frequency (FG/ARB/MOD) : 160/320MHz

• Pulse Generator Frequency : 25MHz

• Power Amplifier : Low Frequency, 100kHz, Output 20W

• True Point by Point Output Arbitrary Waveform Function : 200MSa/s,

• 100MHz Repetition Rate, 14-bit Resolution,16k Point Memory Depth

• Earth Ground Isolation Design Among I/O Terminals and Instrument Chassis

• Frequency Counter : 150MHz, 8 bits

• AM/FM/PM/ASK/FSK/PSK/SUM/PWM Modulation

• USB Host/USB Device/LAN (MFG-22XX only)

• 4.3 Inch TFT Color Display
