주요 특징

• 4” TFT LCD

• Two data display modes

• Standard : two major measurement items + six secondary measurement items

• Simple : displaying test data of four different measurement items

• Met the requirement of IEC 62301 power measurement

• Voltage/ current test frequency bandwidth : DC~6kHz

• Watt resolution : 1mW

• Lowest current range : 5mA, resolution : 0.1uA

• Current/voltage measurements reach CF=3 for distorted wave and CF=6 for half range

• W-h (power vs time)/A-h (current vs time) integration function

• Total harmonic distortion measurement

• Front panel test terminal

• Standard interface : RS-232C, USB device, LAN

• Optional interface : GPIB

• Optional test fixture : GPM-001
