4Cast

  • ITEM 4Cast
  • MODEL 4Cast
  • BRAND UE SYSTEMS
  • · 사양 Save time, save your bearings and improve plant reliability.
데이터시트 카달로그 목록보기
  • ●Smart alert system
  • ●Records data and sounds
  • ●Send data and files to DMS software
  • ●Setup different alarm levels
  • ●Ethernet connection
  • ●Highly flexible
Case
Stainless Steel; Dimensions: 9”x6”x3” (22.8cm x 15.24cm x 7.62cm)
Weight: 4.7 lbs. (2.1 kg)
Power Input
24V, 1 amp (conditioned)
Circuitry
Solid State Analog and SMD Digital with temperature compensation and true RMS conversion
Freq. Response
20kHz-100 kHz Centered around 30 kHz
Operating Temperature
32°F – 122°F (0°C – 50°C)
Transducer
RAS piezoelectric, stainless steel housing
BNC out to BNC in
Length: 25’ (7.62 m), can be ordered up to 100 feet (30,48 m)
Cable
Thread: female 10/32
Ultratrend DMS 6.0 or higher
