주요 특징

• 3.5” color LCD

• 5 models (10Hz~2kHz/20kHz/100kHz/200kHz/300kHz)

• Consecutive test frequency

• Basic accuracy : 0.05%

• Measuring speed up to 25ms (max.)

• Full frequency range or spot OPEN/SHORT

• 16 major/secondary parameter measurement combinations and two additional monitoring parameters(maximum four different parameters can be shown simultaneously)

• DCR measurement and internal D.C. bias voltage (±2.5V)

• PASS/FAIL judgment

• Auto Level Control (ALC) function

• BIN function provides 9BIN and 1AUX, totally 10 BIN

• 10 steps listed tests to select different frequency, voltage and current criteria

• Standard interface : RS-232C, Handler and USB storage

• Compact size, ideal for automatic equipment (2U,1/2 RACK)
