주요 특징

• 500VA AC Test Capacity

• 240x64 Ice Blue Dot matrix LCD

• Sweep Function for DUT characteristic analysis

• Insulation resistance measurement up to 50GΩ(GPT-9903/9904)

• Manual/Auto Mode

• Function Key for quick selection

• High intensity flash for caution & Status indication

• Safety INTERLOCK function

• Zero Crossing Turn-on Operation

• Controllable Ramp-up Time

• True RMS Current Measurement

• High resolution: 1uA for measuring current, 2V for setting voltage

• PWM amplifier to enhance the power efficiency and reliable testing

• Max. 100 memory block for test condition (step) setting. And each step can be named individually.

• Remote terminal on the front panel for “start” and “stop” control

• Rear panel output available

• Interface : RS-232C, USB device, Signal I/O and GPIB (optional)
