주요 특징

• Dual Range Output (0~15V/0~3A) or (0~9V/0~5A)

• 3.5 Inch TFT LCD Display

• Constant Voltage and Constant Current Operation

• Built-in DVM Measurement Function

• High Measurement REsolution (1mV/0.1mA for 5A Range);(1mV/0.1uA for 5mA Range)

• EXternal Relay Control Output On/Off

• Sink Current Capability (Maximum:2A)

• Digital Panel Control

• Selectable Output and Input (DVM) Ports From Front or Rear Panel

• Key Lock Function

• 5 Sets of Preset Memory Including Power Output ON/OFF States

• High Speed Transient Recovery Time(<40us within 100mV ; <80us within 20mV)

• OVP/OCP/OTP Protection to Prevent DUT Damage

• Standard Multiple Interfaces: USB / LAN /GPIB

• Labview Driver and PC Remote Control Software
